Gr2 Titanium ntawv
Khoom npe: Gr2 Titanium Sheet, ASTM B265 Titanium Sheet
Qib: Qib 2
Txuj: ASTM B265
Thickness: 0.019 "(0.5mm) - 0.187" (4.75mm)
Dav: 39.370 "(1000mm) - 78.740" (2000mm)
Ntev: Tsawg dua lossis sib npaug 236.22 "(6000mm)
Ua tiav: Kub dov, Txias dov.
Nto: Polishing, Pickling, 2B.
Kev Them Nyiaj: T / T, L / C.
MOQ: 100kg
Lus Cim: Peb kuj tuaj yeem kho qhov loj me raws li cov neeg siv khoom xav tau.
Khoom Taw qhia
Dab tsi yog Gr2 titanium ntawv
Cov hauv qab no yog cov zaub ntawm titanium daim hlau hauv peb lub rooj cob qhia
ASTM B265 Gr2 Titanium Phaj (Qib 2 Titanium Phaj) yog cov khoom lag luam muaj cov khoom siv titanium ntshiab uas ua tau raws li ASTM Standard B265. Thiab nws cov ntsiab lus titanium yog li 99.6%. Cov khoom siv no tau dhau los ua cov ntaub ntawv siv dav tshaj plaws hauv kev lag luam nrog zoo weldability, formability, thiab processability.Thiab nws kuj yog siv nyob rau hauv kev tsim cov tshav kub exchangers, reactors, cia tso tsheb hlau luam, yeeb nkab liners, thiab lwm yam khoom siv. Kev ua tau zoo thiab kev sib tw ntawm Gr2 titanium ntawv ua rau nws nyiam heev los ntawm cov neeg siv khoom.
Kev faib tawm thiab qhov tsis sib xws ntawm cov titanium sib txawv
|
Khoom npe |
Thickness (hli) |
Dav (mm) |
Ntev (mm) |
|
Daim ntawv titanium
|
0.5-0.8 |
800 max, Ti 6Al-4V |
2000 max |
|
0.8-4 |
1000 max |
3000 max |
|
|
Titanium phaj
|
4-8 |
2000 max |
4000 max |
|
8-100 |
2500 max |
6000 max |
Chemical Cheebtsam ntawm Gr2 titanium ntawv
|
Gr 2 |
N |
C |
H |
Fe |
O |
V |
Pa |
Mo |
Ni |
Ti |
||
|
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
/
|
/ |
/ |
balnc2 |
Mechanical Property ntawm Gr2 titanium ntawv
| Qib 2 |
Tensile zog (min) |
Yeild zog (min) |
Elongation (%) | ||
|
ksi ua |
MPa |
ksi ua |
MPa |
||
|
50 |
345 |
40 |
275 |
20 |
|
Test Methods rau Gr2 Titanium ntawv
|
Qeb |
Txoj Kev Xeem |
|---|---|
| Tshuaj muaj pes tsawg leeg | OES (Optical Emission Spectroscopy) |
|
XRF (X{0}}ray fluorescence) |
|
|
ICP (Inductively Coupled Plasma) |
|
|
Mechanical kuaj |
Tensile xeem (lub zog tensile, yield zog, elongation) |
| Kev kuaj Hardness | |
|
Bending test (muaj feem xyuam rau daim hlau nyias) |
|
|
Tsis yog -kev kuaj kev puas tsuaj (NDT) |
Kev kuaj ultrasonic (UT) |
|
Kev xeem nkag (PT) |
|
|
Kev tshuaj xyuas qhov loj |
Thickness ntsuas (ultrasonic thickness gauge / micrometer) |
|
Kev ntsuas dav thiab ntev |
|
|
Flatness check |
|
|
Kev tshuaj xyuas saum npoo |
Kev kuaj pom pom (ASTM tus qauv) |
|
Surface roughness test |
Qhov zoo ntawm ASTM B265 Gr2 Titanium Sheet
Zoo heev Corrosion Resistance
Titanium tsim cov yeeb yaj kiab TiO₂ tuab thaum nws los rau hauv kev sib cuag nrog oxygen. Nws yog corrosion kuj heev, tiv thaiv Cl⁻ nkag, thiab yog haum rau acidic thiab alkaline ib puag ncig. Nws yog dav siv nyob rau hauv tshuaj, shipbuilding thiab papermaking industries.
Siab tshwj xeeb muaj zog
Lub zog tshwj xeeb: Titanium muaj qhov ntom ntawm 4.51 g / cm³, uas yog kwv yees li 60% ntawm steel.it tuaj yeem txo qhov hnyav ntawm cov qauv thaum tuav lub zog.
Zoo kub kub kuj
Kev kub siab ua haujlwm zoo: Nws tuaj yeem siv rau lub sijhawm ntev ntawm qhov kub thiab txias (qhov ua haujlwm kub ntawm titanium alloy tuaj yeem ncav cuag 400 ~ 600 degree); nws muaj ib tug me me coefficient ntawm thermal expansion thiab zoo thermal stability.
Kev ua haujlwm zoo
Nws tuaj yeem ua tau txias- ua haujlwm thiab kub- ua haujlwm, thiab nws cov kev ua haujlwm txiav tau zoo dua li lwm yam nyuaj-rau- tshuab hlau; nws kuj muaj kev vuam zoo heev.
peb kev tshuaj xyuas rau gr2 titanium phaj
Tshuaj ntsuam xyuas muaj pes tsawg leeg
Txhawm rau kom ntseeg tau cov tshuaj muaj pes tsawg leeg ntawm titanium phaj kom ua tau raws li qhov yuav tsum tau ua ntawm ASTM B265 tus qauv, peb muab cov tshuaj muaj pes tsawg leeg tsom xam ntawm titanium phaj.
Kev ntsuam xyuas cov cuab yeej cuab tam
suav nrog tensile lub zog, tawm lub zog, elongation thiab lwm yam kev ntsuam xyuas, los xyuas seb cov khoom siv ntawm cov khoom ua tau raws li cov qauv.
Tsis yog -kev kuaj kev puas tsuaj
Kev kuaj ultrasonic, eddy tam sim no kuaj thiab lwm txoj kev yog siv los ua 100% tshuaj xyuas ntawm sab hauv thiab saum npoo ntawm titanium phaj kom paub tseeb tias tsis muaj qhov tsis xws luag.
Dimension thiab tsos tshuaj xyuas
Ntsuas qhov tuab, dav, ntev thiab lwm qhov ntev, thiab xyuas qhov zoo ntawm qhov chaw kom ntseeg tau tias nws ua tau raws li qhov tshwj xeeb.
Kev ntsuas kev tiv thaiv corrosion
Kev tiv thaiv corrosion ntawm titanium daim hlau nyob rau hauv ib puag ncig tshwj xeeb raug soj ntsuam los ntawm txoj kev xws li tshuaj tsuag ntsev.
Kev pabcuam peb muab
Peb kuj lees txais qhov thib peb- kev tshuaj ntsuam xyuas thiab txais tos cov neeg siv khoom los npaj kev tshuaj xyuas hauv peb lub rooj cob qhia ua ntej xa khoom..
Cov txheej txheem tsim khoom
Baoji Mingjie Titanium Materials Technology Co., Ltd. tshwj xeeb hauv titanium phaj ntau lawm. Peb cov khoom ua tau raws li cov qauv thoob ntiaj teb rau kev kho mob thiab kev siv tub rog, thiab peb qhov zoo tau lees paub los ntawm kev sim ua tiav, hauv txoj hauv kev no kom lav titanium ruaj khov kev ua haujlwm. Peb tau nruab nrog cov cuab yeej tsim khoom thiab tseem yog ib pab neeg muaj kev paub dhau los nrog ze li 15 xyoo.Peb lub tuam txhab tswj hwm kev tswj hwm nruj ntawm cov txheej txheem tsim khoom, thiab lub sijhawm no peb muab cov txiaj ntsig zoo thiab muaj cov ntawv pov thawj tiav thiab tsim nyog kom tau raws li qhov xav tau ntawm siab -kawg daim ntawv thov.
01
Siab Zoo
Titanium phaj zoo tswj: tag nrho- kev xeem txheej txheem, nruj ua raws li cov qauv los xyuas kom meej kev ua tau zoo.
02
Khoom siv Advanced
Advanced titanium ntau lawm cov khoom: lub tshuab nqus tsev melting kom purity, dov zeb, thiab kev txhawb nqa rau tsis yog -tus qauv customization.
03
Pab neeg tshaj lij
Coj los ntawm cov kws tshaj lij, txhua tus tswvcuab muaj keeb kwm kev lag luam thiab kev tsim nyog rau npe, nrog rau kev paub txog ntau yam haujlwm.
Kev Pabcuam Kev Cai
Peb yog cov neeg siv khoom -centric, teb sai sai rau cov kev xav tau, daws teeb meem kev tshaj lij, thiab tsim muaj txiaj ntsig los ntawm kev pabcuam siab.
